Size:
|
400 |
|
Running tread (b1) [mm]:
|
125 |
|
Wheel width (b2) [mm]:
|
125 |
|
Installation variant:
|
1, corner bearing installation with mechanically machined flange centering |
|
Track form:
|
Without wheel flanges |
|
Bearing:
|
Self-aligning roller bearing 223 15 |
|
Bearing manufacturer:
|
NACHI/TIMKEN |
|
Shaft type:
|
Drive shaft |
|
Crane wheel-shaft connection:
|
Cone |
|
Gear type:
|
A.K 70 |
|
Gear manufacturer:
|
DEMAG |
|
Gear connection type:
|
Splined shaft profile |
|
Shaft end drive (gearing):
|
W75 x 3 x 24 - DIN 5480 |
|
Grease:
|
Multifak EP2 (Texaco) |
|
Temperature range [°C]:
|
-30 to +90 |
|
KG-drawing:
|
KG-011854 |
|
Crane wheel material:
|
EN-GJS-700-2 |
|
Flange bearing housing material:
|
EN-GJS-500-7 |
|
Shaft material:
|
42CrMo4+QT |
|
Painting:
|
Wheel side surface, Flange bearing housing with 2C-PUR single-layer |
|
Color:
|
RAL 5009 (azure blue) |
|
Conservation:
|
Running tread, shaft/shaft end and connecting surfaces of the flanged bearing housings preserved with Tectyl |
|
Shaft accessories:
|
- with retaining ring
|
|
Weight (kg):
|
110 kg |
