ATLAS WHEEL BLOCK SYSTEM
| for wheel-⌀ d1 (mm) | b1 (mm) | b2 (mm) | Wheel load max. in kg |
|---|---|---|---|
| 160 | 46 - 68 | 87 | 6.800 |
| 200 | 46 - 75 | 100 | 10.000 |
| 250 | 55 - 75 | 100 | 12.800 |
| 250-V | 55 - 85 | 110 | 16.000 |
| 315 | 55 - 85 | 110 | 22.000 |
| 60 - 100 | 130 | ||
| 400 | 60 - 120 | 155 | 30.000 |
| 500 | 60 - 130 | 170 | 40.000 |
RB 250 discontinued model, spare parts still available, successor model RB 250-V
Wheel thread
1:1 Interchangable
–30 °C up to +200 °C
Up to 40 tons
High availability
Easy installation
Flexible drive selection
